45mm Performance Miniature Oil Pressure Gauge-BAR

  • 45mm Performance Miniature Oil Pressure Gauge-BAR

    45mm Performance Miniature Oil Pressure Gauge-BAR

    The RICO miniature 45mm gauge series is perfect space saving and low-profile design option for keeping monitor how your vehicle's real time status.



    • Compact in size
    • One glance accuracy
    • Air-Core (Full Sweep Electric)movement
    • Fast reaction
    • Air core chip contained, ability to program to desired position
    • Ability to convert analog to digital(A/D)
    • Customizable appearance and functionality

Product Number

PAC45OPBAR

Product descriptio

Miniature 45mm Gauge Series – Oil Pressure Gauge

Features

True black, low-profile design, space saving. Monitoring vehicle's real status.

Installation

Simply follow our installation sheet.
Sensor is included.

Function

Monitoring engine oil pressure status.

Application

Indoor application.

Place of origin

Taiwan

Mechanical:

Color

Black

Display range

0-7 BAR

Dimension

45mm (cut-off diameter) x 36mm (depth)

Weight

310g



Electrical:

Operating voltage

12V electrical system

Operating temperature

-20 to +85

Power consumption

150mA
